Engine Parts

Engine Piston Set - Kit Part - P3063(8)

2.131" CH. Combustion bowl 0.673" deep, offset to cam side. 1.3080" pin dia. Use M41128 rings.; Sizes : STD

Engine Timing Set - Kit Part - TS391B

w/o balance shaft gears. Crank sprocket has a protruding hub.

Engine Piston Set - Kit Part - P3057(10)

Dish top .069" deep. 1.210" CH. Except "Power Improved". Hyper. Coated skirt. Floating pin. Use S902210 rings.; Sizes : .50

Engine Timing Set - Kit Part - TS391

w/o balance shaft gears. Crank sprocket has no protruding hub.

Engine Cylinder Head Gasket Set - Kit Part - F415HS-A

MLS head gaskets. Intake & plenum gaskets not included. Valve cover gaskets not included use RTV or VCF415. Use new head bolts.

Engine Piston Set - Kit Part - P5014(10)

Dish top .136" deep. 1.210" CH. "Power Improved". Coated skirt. Floating pin. Use S902210 rings.; Sizes : .50

Engine Timing Set - Kit Part - TS391SA

Without cam sprockets. Crank sprocket has hub. Tensioners are cast iron.

Engine Cylinder Head Gasket Set - Kit Part - F330HS-H

From 12/05/00. Use new head bolts.

Engine Cylinder Head Gasket Set - Kit Part - F330HS-D

MLS head gaskets. Use new head bolts.

Engine Piston Set - Kit Part - P3057(8)

Except "Power Improved". Dish top 0.069" deep. 1.210" CH. Hyper. Coated skirt. Floating pin. Use S90228 rings.; Sizes : STD

Engine Timing Set - Kit Part - TS1500

Without cam sprockets. Crank sprocket does not have a hub.

Engine Piston Set - Kit Part - P5014(8)

"L,Z". With "Power Improved" heads. Dish top .136" deep. 1.210" CH. Hyper. Coated skirt. Includes Bi-Fuel. Floating pin. Use S90228 rings.; Sizes : .75

Engine Piston Set - Kit Part - P3097(8)

Flat top. 1.595" CH. Hyper. Coated skirt. Use M40018 rings.; Sizes : 030

Engine Timing Set - Kit Part - TS387G

Engine Cylinder Head Gasket Set - Kit Part - F281HS-N

Contains V/C gaskets w/o bolt hole "eyelets". MLS head gaskets. Use new head bolts.

Engine Timing Set - Kit Part - TS387SG

From 11/02. Chain guides have (2) bolt holes. Crank sprocket has a protruding hub. Tensioners are composite.

Engine Timing Set - Kit Part - TS2200

Thru 10/02. Chain guides have (2) bolt holes. Crank sprocket has a protruding hub. Tensioners are cast iron.

Engine Piston Set - Kit Part - P5013(8)

Dish top .193" x 2.920". 1.210" CH. Hyper. Coated skirt. Floating pin. Use S90228 rings.; Sizes : .75

Engine Piston Set - Kit Part - P5039(8)

Dish top .150" x 3.050". 1.215" CH. Hyper. Coated skirt. Press fit pin. Use S90228 rings.; Sizes : .50

Engine Timing Set - Kit Part - TS387SB

Cam sprockets not included.

Engine Piston Set - Kit Part - P3064(8)

Floating pin. Except "Power Improved or HP Improved". Dish top .159" deep. 1.211" CH. Hyper. Coated skirt. Use S90228 rings.; Sizes : STD

Engine Timing Set - Kit Part - TS387SA

Chain guides have (3) bolt holes. Crank sprocket has no protruding hub. Requires re-using old cam sprocket spacers.

Engine Timing Set - Kit Part - TS387S

Engine Gasket Set - Kit Part - F244C-1

From 7/24/00. MLS head gaskets. Use new head bolts.

Engine Timing Set - Kit Part - TS443A

Engines w/ balance shaft. Partial set. Jackshaft & crankshaft sprockets not included New OE jackshaft bolts required. New OE jackshaft & crank sprockets must be used or warranty is void.

Engine Timing Set - Kit Part - TS443

Engines w/o balance shaft. Partial set. Jackshaft & crankshaft sprockets not incl. New OE jackshaft bolts required. New OE jackshaft & crank sprockets must be used or warranty is void.

Engine Gasket Set - Kit Part - F244B-1

MLS head gaskets. Use new head bolts.

Engine Gasket Set - Kit Part - F232E-1

MLS head gaskets. Use new head bolts.

Engine Gasket Set - Kit Part - F232D-1

MLS head gaskets. Use new head bolts.

Engine Gasket Set - Kit Part - F232C-1

From 1/15/98. 4mm intake gaskets. MLS head gaskets. Use new head bolts.

Engine Gasket Set - Kit Part - F232B-1

Thru 1/14/98. 3mm intake gaskets. MLS head gaskets. Use new head bolts.

Engine Gasket Set - Kit Part - F232H-1

MLS head gaskets. Oil pan gasket not required use RTV. Use new head bolts.

Engine Gasket Set - Kit Part - F232G-1

MLS head gaskets. Oil pan gasket not required use RTV. Use new head bolts.

Engine Cylinder Head Gasket Set - Kit Part - F181HS-C

MLS head gaskets. Use new head bolts.

Engine Timing Set - Kit Part - TS392

w/o sprockets.

Engine Cylinder Head Gasket Set - Kit Part - F181HS-A

MLS head gaskets. Use new head bolts.

Engine Piston Set - Kit Part - P5002(6)

Dome top. 1.171" CH. Hyper. Coated skirt. Use S89186 rings.; Sizes : .50

Engine Timing Set - Kit Part - TS9138

From 12/4/06. 138 link chain. Includes oil pump timing components.

Engine Timing Set - Kit Part - TS393B

w/o sprockets. Engines w/ silent type upper chains only. Fits JTEC & NGC.

Engine Timing Set - Kit Part - TS393

Engines w/ silent type upper chains only. w/ early JTEC cam target wheel. Cam wheel has one "timing window" near the "L" timing mark.
